AutoCal V2 Hardware Specification

Authors list

AutoCal V2 Specification

  • SAE-J1979 CAN protocol.
  • SAE-J1850 VPW protocol.
  • Vehicle Input Voltage - Min 9V, Max 14V.
  • Built-in LCD screen.
  • Upgradeable bootblock and firmware.
  • 8MB internal memory, 6MB (approx.) available for tune/log files.
  • Supports 221 VIN Licenses. (Some AutoCal devices may be configured by the supplier with a smaller maximum VIN license limit.)

AutoCal HD Specification

  • SAE-J1939 CAN protocol.
  • Vehicle Input Voltage - Min 9V, Max 24V.
  • Built-in LCD screen.
  • Upgradeable bootblock and firmware.
  • 8MB internal memory, 6MB (approx.) available for tune/log files.
  • Supports 221 VIN Licenses. (Some AutoCal devices may be configured by the supplier with a smaller maximum VIN license limit.)

Systems Requirements

  • PC or laptop capable of running Windows 7, 8, 8.1 or 10.
  • Optical drive.
  • USB port.
  • Color screen with 1024x768 or greater resolution.
  • 200MB of available disk space.
