Move Files to/from AutoCal V2

Authors list

Move files from AutoCal V2 to PC

To move tune files and log files from AutoCal V2 to your PC;

  1. Connect AutoCal V2 to your PC.
  2. Open EFILive Explorer.
  3. Navigate to the directory on your PC where you wish to save the file.
  4. Navigate to: [F3: Data Files].
  5. Select appropriate folder on your AutoCal device and drag the selected file to your PC.

Move files from PC to AutoCal V2

There are two methods to move tune files from your PC onto AutoCal V2; the method you use with depend on the instructions provided by your tuner.

Program Quick Setup *.bbx file via EFILive V8 Scan and Tune

The [Program Quick Setup] option programs all selected Scan, Tune, Switch, and DTC options, as well as selected device settings, BBX Quick Setup selections and tune files.  Once the device is programmed, AutoCal V2 is configured.

  1. Connect AutoCal V2 to your PC.
  2. Open the EFILive V8 Scan and Tune application.
  3. Select [F5: BBX] option in the left-hand pane.
  4. Select [F6: Quick Setup] option in the left-hand pane.
  5. Select the [Open Quick Setup] button and navigate to the Quick Setup file your tuner has provided.
  6. Select the [Program Quick Setup] to program the configuration into AutoCal V2.
  7. AutoCal V2 users may alter their BBX configuration following the Configure FlashScan and AutoCal for BBX guide, however should discuss this with their tuner before editing their BBX Configuration.

EFILive Explorer

To place tune files from your PC onto AutoCal;

  1. Connect your AutoCal V2 device to your PC.
  2. Open EFILive Explorer.
  3. Navigate to the directory on your PC where you have saved your file from your tuner.
  4. Navigate to: [F3: Data Files].
  5. Select appropriate folder on your AutoCal V2 device and drag the selected file from your PC to AutoCal V2.
